MasterPiece Arms (MPA), manufacturers of the MPA BA Rifles, Chassis Systems, Defender Pistols and Carbines, Suppressors and MPAR Rifles, is pleased to introduce the MPA 22BA Bolt Action Rifle. Built upon the MPA CZ455 BA Chassis, the MPA 22BA Bolt Action Rifle will provide the shooter with the ability to adjust the length of pull, cheek riser position, add side Picatinny rails or a night vision bridge, as well as increase the distance from the spigot mounted bipod to the rear support. Chambered in 22LR, the MPA 22BA Bolt Action Rifle can change to 22WMR and 17HMR through a barrel change. The rifle also includes an MPA Trigger Shoe and DIP25MOA Picatinny scope base.

MasterPiece Arms Introduces the MPA 22BA Bolt Action Rifle

The chassis is machined on MPA’s CNC Horizontal Machining Centers to exacting tolerances from 6061 aluminum. MPA’s unique pocketing system reduces weight and increases the structural integrity of the chassis. The chassis also includes a built-in bubble level, thumb notch and spigot mount with lower mounted Picatinny rail. The new MPA Enhanced Vertical Grip is also included. It is also compatible with a user locatable barricade stop system, which requires the purchase of a rotating barricade stop.

The MPA 22BA Bolt Action Rifle includes a precision gun drilled, reamed and honed Spencer / MPA rifle barrel made from 416RQ stainless steel. The hand lapped barrel is bore and land inspected on a video borescope. The chamber is indicated within 0.0001″ or less to the bore of the rifle.

The MPA produced buttstock features an adjustable length of pull, recoil pad with height and cant adjustment, adjustable cheek riser and an adjustable monopod. The length of pull and cheek position are locked in place via a set of screws that are embedded into the buttstock body. It provides very strong lockup of the cheek riser plate and recoil plate assembly.

MPA 22BA Bolt Action Rifle Specifications:
Caliber:
22 LR (caliber change to 22MWR and 17HMR through barrel change)
Action:
CZ455
Chassis:
MPA CZ455 BA Chassis
Chassis Weight:
3.2 lbs.
Barrel:
416RQ Stainless Steel Spencer / MPA barrel
Barrel Twist:
1:16
Barrel Length:
16-24″ (customer specified)
Barrel Muzzle Thread:
½-28 TPI (if requested)
Barrel Profile:
0.920″ straight
Coating:
Cerakote
Length of Pull:
13.50 – 14.75″ (youth model available)
Trigger:
CZ455 Trigger (yoDave Trigger Upgrade)
Trigger Pull:
1 – 3 lbs.
Magazine:
CZ455 10 round polymer magazine with DIP floorplate
MSRP:
$1,599.00


The MPA 22BA Bolt Action Rifle is available in black, burnt bronze, flat dark earth, gunmetal, marine red, NRA blue, sniper green and tungsten. All chassis are Cerakoted in a multitude of colors. Solid colors are included. Custom Cerakote colors have a $135 upcharge for the chassis body and $65 for the barreled action.

MPA makes every effort to get the product to the customer as quickly as possible. Please allow eight to 12 weeks before delivery from date of order as these are hand built precision instruments and not production components.

For more information on MasterPiece Arms and their product line of pistols, rifles, carbines and suppressors, visit www.masterpiecearms.com.
